TCS3200 Colour Recognition Sensor
1. General Specifications
Detection Method: Optical Light Sensing
Sensing Technology: Photodiode Array
Colour Detection: Red, Green and Blue (RGB)
Output Type: Digital Frequency
Light Source: Onboard White LEDs (module-dependent)
2. Colour Detection Specifications
Red Detection: Supported
Green Detection: Supported
Blue Detection: Supported
Clear Photodiodes: Supported
Photodiode Array: 8 × 8 (64 photodiodes)
Red Filter Photodiodes: 16
Green Filter Photodiodes: 16
Blue Filter Photodiodes: 16
Clear Photodiodes: 16
Output Frequency: Proportional to detected light intensity
3. Electrical Specifications
Operating Voltage: 2.7V–5.5V DC (sensor IC)
Recommended Module Supply: 3V–5V DC (module-dependent)
Output Signal: Digital square wave
Power Consumption: Low
4. Interface and Connectivity
VCC: Positive power supply
GND: Ground connection
S0: Output frequency scaling selection
S1: Output frequency scaling selection
S2: Colour filter selection
S3: Colour filter selection
OUT: Frequency output signal
OE: Output enable (active LOW)
Controller Compatibility: Arduino, ESP32, STM32 and other compatible microcontrollers
5. Applications
RGB Colour Detection
Automatic Colour Sorting Machines
Object Identification Systems
Line Following and Colour Detection Robots
Industrial Colour Inspection
Smart Packaging and Product Sorting
Arduino and ESP32-Based Robotics Projects
Note: The TCS3200 does not directly output RGB digital values. It generates a frequency signal corresponding to the selected colour filter. A microcontroller measures these frequencies to determine the colour. Actual detection accuracy depends on lighting, distance, and calibration.
