GY-MAX4466 Sound Sensor Module

1. Specifications

  • Module Model: GY-MAX4466

  • Amplifier IC: MAX4466

  • Sensor Type: Acoustic Sensor

  • Detection Method: Sound Wave Detection

  • Output Type: Analog

  • Amplification Type: Audio Signal Amplification

  • Gain Adjustment: Adjustable

2. Sound Detection Specifications

  • Sound Detection: Ambient Sound and Voice

  • Frequency Response: Approximately 20 Hz–20 kHz (microphone and circuit dependent)

  • Audio Signal Output: Analog waveform

  • Sound Sensitivity: Depends on microphone and gain setting

  • Gain Range: Approximately 25× to 125×

  • Gain Adjustment: Onboard potentiometer

3. Electrical Specifications

  • Recommended Supply Voltage: 3.3V–5V DC

  • Operating Current: Approximately 0.6 mA (typical)

  • Output Voltage: Analog signal centered around a DC bias

  • Output Signal: Amplified audio waveform

  • Power Consumption: Low

4. Interface and Connectivity

  • VCC: Positive power supply

  • GND: Ground connection

  • OUT: Analog audio signal output

  • Output Interface: Analog

  • Controller Compatibility: Arduino, ESP32, STM32 and other compatible microcontrollers

7. Applications

  • Sound Level Monitoring

  • Voice Detection Systems

  • Noise Monitoring

  • Sound-Activated Switching

  • Audio Signal Processing

  • Voice-Controlled Robotics

  • Arduino and ESP32-Based IoT Projects

Note: The MAX4466 module provides an amplified analog audio waveform, not a calibrated sound-level measurement in decibels (dB). Additional signal processing and calibration are required for accurate sound-level measurement.
