PowMr Solar Inverter Charger 5500W

Availability:

Out of stock

  • Pure sine wave inverter
  • Configurable input voltage range for home appliances and personal computers via LCD setting
  • Configurable battery charging current based on applications via LCD setting
  • Configurable AC/Solar Charger priority via LCD setting

Price range: Rs 274,000.00 through Rs 315,000.00

powmr

PowMr Solar Inverter Charger 5500W

  • Built-in MPPT 100A All In One Solar Controller
  • MAX PV Input 500V
  • DC Out Put 220VAC
  • 48VDC System
  • 5.5KW Pure Sine Wave hybrid inverter With
  • WiFI (Not Included WIFI Module)

INTRODUCTION

This is a multi-function all in one inverter charger, combining functions of inverter, solar charger, and battery charger to offer uninterruptible power support with portable size. Its comprehensive LCD display offers user-configurable and easy-accessible button operations such as battery charging current, AC/solar charger priority, and acceptable input voltage based on different applications.

Features of PowMr Solar Inverter Charger 5500W

  1. Brand: PowMr
  2. Product Model: VM PLUS-5.5KW-WIFI
  3. Pure sine wave inverter
  4. Input voltage range for home appliances and personal computers via LCD setting that is configurable
  5. Battery charging current based on applications via LCD setting that is configurable
  6. AC/Solar Charger priority via LCD setting also that is configurable
  7. Compatible to mains voltage or generator power
  8. Auto restart while AC is recovering
  9. The voltage that starts to connect to the solar panel must be above 150V for the Hybrid inverter to work normally
  10. Overload/ Over temperature/ short circuit protection
  11. Smart battery charger design for optimized battery performance
  12. Cold start function

Data Sheet

INVERTER MODEL3.5KW5.5KW
Input Voltage WaveformSinusoidal (utility or generator)
Nominal Input Voltage230Vac
Low Loss Voltage170Vac±7V (UPS); 90Vac±7V (Appliances)
Low Loss Return Voltage180Vac±7V (UPS); 100Vac±7V (Appliances)
High Loss Voltage280Vac±7V
High Loss Return Voltage270Vac±7V
Max AC Input Voltage300Vac
Nominal Input Frequency50Hz/ 60Hz (Auto detection)
Low Loss Frequency40±1Hz
Low Loss Return Frequency42±1Hz
High Loss Frequency65±1Hz
High Loss Return Frequency63±1Hz
Output Short Circuit ProtectionCircuit Breaker
Efficiency (Line Mode)>95% (Rated R load, battery full charged )
Transfer Time10ms typical (UPS); 20ms typical (Appliances)
INVERTER MODEL3.5KW5.5KW
Rated Output Power3.5KW5.5KW
Output Voltage WaveformPure Sine Wave
Output Voltage Regulation230Vac±5%
Output Frequency50Hz
Peak Efficiency93%
Overload Protection5s@>150% load; 10s@110%-150% load
Surge Capacity2* rated power for 5 seconds
Nominal DC Input Voltage24Vdc48Vdc
Cold Start Voltage23.0Vdc46.0Vdc
Low DC Warning Voltage
@ load < 50%23.0Vdc46.0Vdc
@ load > 50%22.0Vdc44.0Vdc
Low DC Warning Return Voltage
@ load < 50%23.5Vdc47.0Vdc
@ load > 50%23.0Vdc46.0Vdc
Low DC Cut-ofF Voltage
@ load < 50%21.5Vdc43.0Vdc
@ load > 50%21.0Vdc42.0Vdc
High DC Recovery Voltage32Vdc62Vdc
High DC Cut-ofF Voltage33Vdc63Vdc
No Load Power Consumption<35W
Utility Charging Mode
INVERTER MODEL3.5KW5.5KW
Charging Algorithm3-Step
AC Charging Current (Max)80Amp (@Vi/p=230Vac)60Amp (@Vi/p=230Vac)
Floating Charging Voltage27Vdc54Vdc
MPPT Solar Charging Mode
INVERTER MODEL3.5KW5.5KW
Max. PV Array Power5000W5500W
Nominal PV Voltage240Vdc240Vdc
PV Array MPPT Voltage Range120-450Vdc120-450Vdc
Max. PV Array Open Circuit Voltage500Vdc500Vdc
Max Charging Current (AC charger plus solar charger)100Amp80Amp
INVERTER MODEL3.5KW5.5KW
Safety CertificationCE
Operating Temperature Range-10°C to 50°C
Storage temperature-15°C- 60°C
Humidity5% to 95% Relative Humidity (Non-condensing)
Dimension (D*W*H), mm100 x 300 x 440
Net Weight, kg9.59.7
