MAX15MA Voltage To Current Module 5V to 20mA Linear Output Conversion Board

MAX15MA Voltage To Current Module 5V to 20mA Linear Output Conversion Board

Description

Voltage To Current Module 0-5V to 0-20mA Linear Output MAX15MA Conversion Board MCU Embedded Direct Acce to AD converter

Specification:

Working voltage: DC 10V~30V
Conversion range: 0-5V voltage is converted into 0-20mA current
VCC: working power supply 10V-30V
GND: working power ground
VIN: Input voltage 0-5V
GND: input voltage ground
OUT: output current 0-20mA
GND: output ground

1. Drive capability MAX15MA, linear output.

2. Using the single-chip embedded technology, the output signal can be directly connected to the AD converter.

3. Convert the voltage (0~5V) on the industrial standard to the current (0~10mA, 4~20mA) on the industrial standard.

4. It is easy to operate, can be fine-tuned by a potentiometer, and can be connected to a single-chip microcomputer with AD function.

Operation instructions: The working voltage is connected to VCC and GND,

The VIN terminal is connected to a controllable voltage, the range is 0-5V, and the output terminal has a corresponding current output.

The correspondence between voltage and current can be fine-tuned and calibrated by adjusting the potentiometer.
