GT-070-26MR-1TC1AI 7″ HMI + PLC

GT-070-26MR-1TC1AI 7″ HMI + PLC with Thermocouple & Analog Input (No Wireless)

GT-070-26MR-1TC1AI compact all‑in‑one industrial controller combining a 7.0″ touchscreen HMI with built‑in PLC logic. Includes relay outputs, pulse counters, thermocouple and analog input channels. Ideal for process automation where IoT connectivity is not required.

Display & Dimensions

• Screen Size: 7.0″ (16:9), resolution 1024 × 600 pixels

• Touch Panel: 4‑wire resistive

• Color Depth: 16.77 million colors; LED backlight; brightness ~450 cd/m²; contrast ~400:1

• External Dimensions: 204 × 148 × 45 mm (cut‑out size: 192 × 138 mm)

• Weight: ~700 g

• Housing: ABS + PC engineering plastic



PLC I/O & Measurement Capabilities

• Total I/O: 26 channels (mixed)

• Relay Outputs: Up to 10 relay channels

• High-Speed Counters: 4 channels supporting up to 200 kHz pulse counting

• Thermocouple Input: 1 channel (K/T type support)

• Analog Input: 1 channel for voltage/current measurement

• Expansion: Supports up to 16 additional I/O channels via plugin modules

Connectivity & Interfaces

• Communication Ports: USB download port and USB-host port for firmware or file transfer; RS‑485 port for PLC or external host communication

• Ethernet: Integrated for Modbus TCP/IP control

• Wireless: No built‑in Wi‑Fi or 4G support in non‑G version

Hardware & Control Software

• Processor: Dual-core Cortex‑A7 @ ~1 GHz

• Memory: 128 MB Flash + 128 MB DDR3 RAM

• Programming: Compatible with SKTOOL v7.1+; supports ladder logic, macro scripting, alarms, data logging, multilingual UI, and integration with 300+ PLC protocols

Safety, Certifications & Environmental Specs

• Power Input: DC 24 V ±15%

• Insulation Test: Withstands 1000 V AC for 1 minute

• ESD Protection: Class 4 (~±6 kV) electrostatic discharge resistance

• Ingress Protection: IP65-rated front panel (dust/splash resistant)

• Certifications: FCC Class A; CE-rated to EN55032 and EN55035 standards

• Operating Conditions: –20 °C to +55 °C (non‑freezing), 5–95% RH (non-condensing), vibration resistance up to 2 G at 10–25 Hz for 30 min per axis



Summary Table
