The Airtac HFD20X40 is a double-acting pneumatic gripper featuring a 20 mm bore and 40 mm stroke. It’s engineered for applications requiring compact size, high rigidity, and precise gripping force.
Key Features:
Double-Track Design: Enhances load span and bending moment (Mr) load capacity.
Double Piston Drive: Provides double output for greater clamping force.
Positioning Hole: Located at the bottom of the body to improve precision and consistency in repeated dismounting and positioning.
Stainless Steel Jaw Rails: Offer high rigidity and corrosion resistance.
Flexible Mounting: Can be fixed in four directions, providing a high degree of freedom.
Reduced Height: Overall height is reduced by about 50% compared to parallel jaw products of the same clamping force, effectively reducing device space and sloshing moment.
Specifications:
Parameter
Details
Bore Size
20 mm
Stroke Length
40 mm
Acting Type
Double-acting
Operating Pressure
0.15–0.7 MPa (22–100 psi)
Proof Pressure
1.2 MPa (12 bar)
Temperature Range
-20°C to +70°C
Lubrication
Not required
Repeatability
±0.05 mm
Max Frequency
120 cycles per minute (for middle and short strokes)
Port Size
M5x0.8
Applications:
The HFD20X40 is suitable for various automation tasks, including:
Precision Handling: Ideal for tasks requiring accurate gripping and placement.
Robotic Arms: Used in robotic systems for component manipulation.
Assembly Lines: Facilitates efficient assembly processes in manufacturing.
Packaging Systems: Assists in packaging operations by securely holding items.
