AirTAC ACQ32X15S – Compact Pneumatic Cylinder

ACQ32X15S – Compact Pneumatic Cylinder (ACQ Series)

The ACQ32X15S is a premium compact, double-acting pneumatic cylinder from AirTAC’s ACQ line. Engineered for minimal installation space while delivering reliable linear motion, this model features a 32 mm bore, a short 15 mm stroke, and comes with a magnet and female PT-threaded rod for easy integration with sensors and mounting accessories. It follows JIS standards and incorporates designs that enhance durability, sealing, and compactness.

Key Features:

• Double-acting operation (push & pull) with a compact design.

• Equipped with a built-in magnet (for sensor detection).

• Female rod end with PT thread type.

• JIS standards compliance.

• C-clip construction (compact and reliable) connecting body parts, riveted piston-rod for strength.

• Hard anodizing on internal barrel to resist abrasion and wear.

• Heterogeneous two-way seal structure with grease reservation.

• Magnetic switch slots around the cylinder body for easy sensor installation.

Specifications:

Applications:

This cylinder is ideal for applications where space is tight but precision is required. Examples include:

• Industrial automation with compact layout constraints

• Pick & place mechanisms

• Sensor-integrated pneumatic systems

• Jig, fixture, or tooling operations where short strokes are adequate

• Any linear motion setup where detecting piston position (via magnet + sensor) is needed
