GC-070-32MAA-C Samkoon DC 24V Integrated PLC & 4.3inch 480*272 HMI

The Samkoon GC-070-32MAA-C is a combination of a Programmable Logic Controller (PLC) and Human Machine Interface (HMI) in a single integrated unit.

Specifications:

• Model: GC-070-32MAA-C
• Power Supply: 24V DC
• Display Size: 4.3 inches
• Display Type: TFT LCD
• Resolution: 480 x 272 pixels
• Touchscreen: Yes, resistive touch

PLC Section:

• Processor: High-speed ARM-based microcontroller
• I/O Configuration:
  • Digital Inputs: 16 channels (24V DC, sink/source type)
  • Digital Outputs: 16 channels (Transistor, sink type)
  • Analog Inputs: None
  • Analog Outputs: None
• Expansion: Supports external I/O modules via an expansion port
• Communication Ports:
  • RS232: 1 port (for communication with external devices)
  • RS485: 1 port (supports Modbus RTU communication)
  • Ethernet Port: None
  • USB Port: For programming and data logging
• Memory:
  • Program Memory: 32K words
  • Data Memory: 10K words
  • Flash Memory: 128K for user programs

HMI Section:

• Screen: 4.3″ TFT color screen, 65K colors
• Resolution: 480 x 272 pixels
• Brightness: Adjustable
• Touchscreen Type: Resistive
• Storage: Flash memory for data logging and recipe management
• Communication Protocols: Supports Modbus RTU, and custom communication protocols via RS232/RS485
• Programming Software: Samkoon SKWorkshop
• USB: For program upload/download and data transfer
• Real-Time Clock: Yes, with a backup battery for time-keeping

Dimensions and Installation:

• Dimensions: Approx. 195 mm x 138 mm x 45 mm
• Mounting: Panel mount, with IP65 sealing for the front panel
• Weight: Around 0.9 kg

Programming and Compatibility:

• Programming Language: Ladder Logic (LD), Function Block Diagram (FBD)
• Software: Samkoon HMI and PLC programming environment (SKWorkshop)
• Communication Protocols: Supports Modbus RTU, custom protocols

Other Features:

• Password Protection: Yes, to secure user access and settings
• Data Logging: Yes, with support for saving logs on external USB drives
• Recipe Management: Yes, with internal memory support
• Alarm Handling: Built-in alarm system for monitoring operations
