CPU224XP PLC control PPI CPU224 with Ethernet 14 in 10 relay transistor out 187.5Kb compatible with Siemens S7-200
The CPU224XP PLC control PPI is a reliable and efficient control system designed for industrial automation. With its advanced features and high-performance capabilities, it provides seamless communication and precise control over various processes. This PLC control unit offers a user-friendly interface and is compatible with a wide range of devices, making it suitable for diverse applications. Whether you need to monitor and control machinery or manage complex systems, this is a dependable choice that ensures optimal performance and productivity.
Key Features & Benefits
100% STEP 7-Micro/WIN Software Compatibility: Programs directly using Siemens STEP 7-Micro/WIN (V4.0 SP9 recommended) with support for Ladder Diagram (LAD), Statement List (STL), and Function Block Diagram (FBD).
Native RJ45 Ethernet Port: Enables high-speed program upload, download, and online monitoring over standard Ethernet cables. Supports Siemens S7 TCP Ethernet protocol and Modbus TCP for direct communication with modern HMIs, SCADA platforms, and OPC servers.
Dual Serial PPI / RS485 Support: Features an isolated RS485 port supporting PPI (Point-to-Point Interface), Freeport, and Modbus RTU at baud rates up to 187.5 kbps for connecting HMIs, VFDs, and smart meters.
Integrated Analog Capabilities: Onboard 2 analog voltage inputs (0–10V) and 1 analog output (0–10V / 0–20mA) for direct PID temperature loops, pressure sensing, and VFD speed referencing without needing external analog expansion blocks.
High-Speed Counting & Motion Control:
High-Speed Counters (HSC): 6 high-speed counters (up to 30 kHz / 200 kHz dependent on mode) supporting single-phase and AB-quadrature encoder inputs.
High-Speed Pulse Outputs (Transistor models): Dual 20 kHz / 100 kHz PTO/PWM pulse outputs for stepper and servo positioning control.
Non-Volatile Data Retention: Built-in EEPROM flash memory ensures user programs and critical parameter registers (V-memory) persist indefinitely during power outages without relying on a battery.
- Package: Yes
- Model Number: Siemens PLC
- Type: Embedded Industrial Motherboard
- Brand Name: SEEKU
- Origin: Mainland China
package included:
PLC board*1
Attn: Board works similarly to Siemens same model PLC, and compatible with the software. Any questions please contact customer service. Thanks.
