12 Core Multi-Colour IDC Flat Wire Ribbon

Specifications

• Number of Cores: 12
• Core Colours: Multi-colour (Rainbow)
• Cable Type: Flat Ribbon Cable
• Conductor Material: Tinned Copper
• Conductor Size: 26 AWG
• Conductor Construction: 7 × 0.16 mm Stranded
• Conductor Pitch: 1.27 mm (0.05″)
• Cable Width: Approximately 15.24 mm
• Insulation Material: PVC
• Temperature Range: -20°C to +105°C
• Shielding: Unshielded
• Connector Compatibility: Standard 2.54 mm IDC Connectors
• Flexibility: High-flexibility flat cable design
• Compliance: RoHS Compliant

Features

• 12 colour-coded conductors for easy identification.
• Flat profile for neat and compact cable management.
• Suitable for IDC crimp connectors.
• Flexible PVC insulation for durability.
• Easy to split individual conductors where required.
• Excellent for low-voltage signal transmission.

Applications

• PLC and HMI connections
• Industrial automation systems
• Control panels
• Embedded systems
• Arduino and Raspberry Pi projects
• Internal equipment wiring
• Robotics and automation
• Signal and data transmission
• Prototype and test equipment
